Rain Deflector Xtreme Dock Shelter

RAIN DEFLECTOR XTREME (RD) IS DESIGNED TO FIT OVER ALL SEALS AND ALMOST ANY TYPE OF SHELTER

Rain Deflector Xtreme — provides an excellent barrier to water runoff from the tops of trailers entering the building, especially at declined docks. The RD Xtreme is designed for docks that service a wide range of vehicles and can seal most trailer sizes. Designed for versatility, it is compatible with all docks seals and most dock shelters.

FEATURES AND BENEFITS

• Multi-layer water defense system
• Mounts over existing seals and shelters or can be combined with a new installation for a seamless product
• Covers truck heights ranging from 12’6 to 13’6-inches
• 20-inch projection beyond the seal/shelter for greater coverage
• 5-inch foam-filled pad deters water runoff from trailer tops
• High-density polyurethane foam for added resiliency
• Frame is made from pressure-treated, kiln-dried wood
• Side flaps with stay pockets for draft protection
• Heavy-duty steel brackets provide reinforced snow load support
• Raked header for enhanced water drainage
• Header has a translucent fiberglass top
• Face is removable for quick replacements when necessary
• All sew lines are lock-stitched and reinforced with UV-resistant thread

OPTIONS

• Custom projection up to 48-inches total from wall
• Traditional head curtain
• Pad drop over 44-inches
• Frame cut-outs for obstructions
• Galvanized steel head frame
• Spring steel stays
• Overhead cable supports*

*Cables required for certain applications
